Hardener EPIKURE™ Curing Agent 943 (100 - 200 min)

Hardener EPIKURE™ Curing Agent 943 (100 - 200 min)

Hardener for Epoxy Resin EPIKOTE™ Resin L 20

  • Very low viscosity (13 ± 2 mPa•s, at 25 °C)

Epoxy Resin EPIKOTE™ Resin L 20 + Hardener EPIKURE™ Curing Agent 943

The combination of Epoxy Resin EPIKOTE™ Resin L 20 and Hardener EPIKURE™ Curing Agent 943 yields an extremely low-viscosity epoxy resin system of medium reactivity and superior impregnating and wetting properties to glass, aramid, and carbon fibres.


Application:
Due to its good impregnation properties, it is preferably used for the production of heavy-duty fibre composite components using the winding process.


Processing:

Processing: 100 - 200 minutes

Mixing ratio:
100 : 24
parts by weight of EPIKOTE™ Resin L 20 : EPIKURE™ Curing Agent 943

Curing time:

  1. 8 - 10 h at room temperature, followed by 8 - 10 h hot curing at 60 °C
  2. To shorten curing: 3 h at 30 - 40 °C + 8 -10 h at 60 °C
  3. For greatly enhanced thermoforming stability (TG approx. 110 °C):
    Curing as in 1. or 2. + post curing 6 - 10 h at 120 °C with a temperature heating rate of 20K/h.

Technical Data:

Physical properties
(at time of processing):

Property EPIKOTE™
Resin L20
EPIKURE™ Curing Agent 943
Viscosity at 25 °C in mPa*s 900 ± 150 13 ± 2
Density at 20 °C in g/cm³ 1.15 ± 0,01 0.92 ± 0.01
Colour (Gardner) < 3
Epoxy-äquivalent weight in g/äquiv. 175.5 ± 3.5
Amine-äquivalent weight in g/äquiv.   43
Refractive index at 25 °C 1.5495 ± 0.0030
Pot life at 20-25 °C in min 100-200

Material characteristics (pure resin cured)
Epoxy resin EPIKOTE™ Resin L 20
with Hardener EPIKURE™ Curing Agent 943

Flexural strength in MPa 545
Bending E-modulus in MPa 24.000
Compressive strength in MPa 380
Impact strength in mJ/mm2 220
ILSS in MPa 38

Please order Epoxy Resin EPIKOTE™ Resin L 20 separately.

westlake

Hardener EPIKURE™ Curing Agent 943, bottle/ 480 g

Item no.  1121281 Only 4 left in stock, more on the way  (delivery time 1-2 days)

Add to Shopping List

19,15
(Base Price 39,90 € /  kg)

Scaled Price

  • From Qty 2:  5,00%
  • From Qty 5:  10,00%
- +
westlake

Hardener EPIKURE™ Curing Agent 943, bottle/ 960 g

Item no.  1121282 Only 2 left in stock, more on the way  (delivery time 1-2 days)

Add to Shopping List

34,11
(Base Price 35,53 € /  kg)

Scaled Price

  • From Qty 2:  5,00%
  • From Qty 5:  10,00%
- +
westlake

Hardener EPIKURE™ Curing Agent 943, canister/ 4,8 kg

Item no.  1121283 Only 2 left in stock, more on the way  (delivery time 1-2 days)

Add to Shopping List

131,38
(Base Price 27,37 € /  kg)

Scaled Price

  • From Qty 2:  5,00%
  • From Qty 5:  10,00%
- +
westlake

Hardener EPIKURE™ Curing Agent 943, canister/ 9,6 kg

Item no.  1121284 Only 2 left in stock, more on the way  (delivery time 1-2 days)

Add to Shopping List

254,78
(Base Price 26,54 € /  kg)

Scaled Price

  • From Qty 2:  5,00%
  • From Qty 5:  10,00%
- +
westlake

Hardener EPIKURE™ Curing Agent 943, canister/ 24 kg

Item no.  1121285 Short delivery time

Add to Shopping List

597,73
(Base Price 24,91 € /  kg)

Scaled Price

  • From Qty 2:  5,00%
  • From Qty 5:  10,00%
- +

all Prices  price incl. VAT, possibly plus shipping

Article information

type: ga
language: [language]
info3: [info3]
filetype: [filetype]
url: [url]
Instructions for use
type: si
language: [language]
info3: [info3]
filetype: [filetype]
url: [url]
MSDS
type: pi
language: [language]
info3: [info3]
filetype: [filetype]
url: [url]
Product information
type: td
language: [language]
info3: [info3]
filetype: [filetype]
url: [url]
type:
language: [language]
info3: [info3]
filetype: [filetype]
url: [url]

Hazards identification - Hardener EPIKURE™ Curing Agent 943

Hazard components for labelling

3-aminomethyl-3,5,5-trimethyl-cyclohexylamine

Signal word: Danger

Pictograms:

GHS05 GHS07

Hazard statements

H302 Harmful if swallowed.
H314 Causes severe skin burns and eye damage.
H317 May cause an allergic skin reaction.

Precautionary statements

P261 Avoid breathing dust/fume/gas/mist/vapours/spray.
P264 Wash hands thoroughly after handling.
P270 Do no eat, drink or smoke when using this product.
P280 Wear protective gloves / protective clothing / eye protection / face protection.
P303 P361 P353 IF ON SKIN (or hair): Remove/Take off immediately all contaminated clothing. Rinse skin with water or shower.
P305 P351 P338 P310 IF IN EYES: Rinse continuously with water for several minutes. Remove contact lenses if present and easy to do. Continue rinsing. Immediately call a POISON CENTER or doctor / physician.
P311 Call a POISON CENTER/doctor.
P333 P313 If skin irritation or a rash occurs: Get medical advice / attention.
P362 P364 Take off contaminated clothing and wash it before reuse.

Hazards identification - Epoxy Resin EPIKOTE™ Resin L 20

Hazard components for labelling

reaction product: bisphenol-A-(epichlorhydrin)
epoxy resin (number average molecular weight <= 700)

Signal word: Warning

Pictograms:

GHS07 GHS09

Hazard statements

H315 Causes skin irritation.
H317 May cause an allergic skin reaction.
H319 Causes serious eye irritation.
H411 Toxic to aquatic life with long lasting effects.

Precautionary statements

P261 Avoid breathing dust/fume/gas/mist/vapours/spray.
P264 Wash hands thoroughly after handling.
P273 Avoid release to the environment.
P280 Wear protective gloves / protective clothing / eye protection / face protection.
P305 P351 P338 IF IN EYES: Rinse continuously with water for several minutes. Remove contact lenses if present and easy to do. Continue rinsing.
P333 P313 If skin irritation or a rash occurs: Get medical advice / attention.
P337 P313 If eye irritation persists: Get medical advice / attention.
P362 P364 Take off contaminated clothing and wash it before reuse.
P391 Collect spillage.

Special labelling of certain mixtures

EUH205 Contains epoxy constituents. May produce an allergic reaction.
